OPTO TRT SMD 35V 50MA 3.6X4.4
Referencia: PC357Description
PC357NJ0000F Series contains an IRED optically coupled to a phototransistor. It is packaged in a 4-pin Mini-flat package. Input-output isolation voltage(rms) is 3.75kV. Collector-emitter voltage is 80V and CTR is 50% to 600% at input current of 5mA.
Features
1. 4-pin Mini-flat package
2. Double transfer mold package (Ideal for Flow Soldering)
3. High collector-emitter voltage (V CEO : 80V)
4. Current transfer ratio (CTR) : MIN. 50% at I F=5mA,VCE=5V
5. Several CTR ranks available
6. High isolation voltage between input and output (Viso(rms) : 3.75kV)
7. Lead-free and RoHS directive compliant
Todos los datos de compra son encriptados y protegidos
Envío en 48/72 horas
14 días de devolución
Description
PC357NJ0000F Series contains an IRED optically coupled to a phototransistor. It is packaged in a 4-pin Mini-flat package. Input-output isolation voltage(rms) is 3.75kV. Collector-emitter voltage is 80V and CTR is 50% to 600% at input current of 5mA.
Features
1. 4-pin Mini-flat package
2. Double transfer mold package (Ideal for Flow Soldering)
3. High collector-emitter voltage (V CEO : 80V)
4. Current transfer ratio (CTR) : MIN. 50% at I F=5mA,VCE=5V
5. Several CTR ranks available
6. High isolation voltage between input and output (Viso(rms) : 3.75kV)
7. Lead-free and RoHS directive compliant
